Annotate figures including: i) ggplots, ii) arranged ggplots from ggarrange(), grid.arrange() and plot_grid().

annotate_figure(
  p,
  top = NULL,
  bottom = NULL,
  left = NULL,
  right = NULL,
  fig.lab = NULL,
  fig.lab.pos = c("top.left", "top", "top.right", "bottom.left", "bottom",
    "bottom.right"),
  fig.lab.size,
  fig.lab.face
)

Arguments

p

(arranged) ggplots.

top, bottom, left, right

optional string, or grob.

fig.lab

figure label (e.g.: "Figure 1").

fig.lab.pos

position of the figure label, can be one of "top.left", "top", "top.right", "bottom.left", "bottom", "bottom.right". Default is "top.left".

fig.lab.size

optional size of the figure label.

fig.lab.face

optional font face of the figure label. Allowed values include: "plain", "bold", "italic", "bold.italic".

See also

Examples

data("ToothGrowth") df <- ToothGrowth df$dose <- as.factor(df$dose) # Create some plots # :::::::::::::::::::::::::::::::::::::::::::::::::: # Box plot bxp <- ggboxplot(df, x = "dose", y = "len", color = "dose", palette = "jco") # Dot plot dp <- ggdotplot(df, x = "dose", y = "len", color = "dose", palette = "jco") # Density plot dens <- ggdensity(df, x = "len", fill = "dose", palette = "jco") # Arrange and annotate # :::::::::::::::::::::::::::::::::::::::::::::::::: figure <- ggarrange(bxp, dp, dens, ncol = 2, nrow = 2)
#> `stat_bindot()` using `bins = 30`. Pick better value with `binwidth`.
annotate_figure(figure, top = text_grob("Visualizing Tooth Growth", color = "red", face = "bold", size = 14), bottom = text_grob("Data source: \n ToothGrowth data set", color = "blue", hjust = 1, x = 1, face = "italic", size = 10), left = text_grob("Figure arranged using ggpubr", color = "green", rot = 90), right = text_grob(bquote("Superscript: ("*kg~NH[3]~ha^-1~yr^-1*")"), rot = 90), fig.lab = "Figure 1", fig.lab.face = "bold" )
